Center Enamel is a leading design and manufacturing company that provides anaerobic digester tank design and manufacture, installation.

Glass fused to steel provides superior corrosion resistance to acids, alkalis, water, and other chemical solutions.

Glass fused to steel technology is the premium coating technology in the storage tank industry.

As a result of this chemical resistance, glass linings can serve for more than 30 years in environments that would quickly render most metal vessels unserviceable.

Glass fused to steel tank is a kind of factory fabrication tank, which made of glass coated on Ti-rich special steel plates.

The steel plates are coated with enamel powder ( mixing with 10-20 different materials ) and burned in an oven ( Temperature from 800 celsius to 950 celsius ), which makes the steel sheet and glass coated greatly blend together.

High recommended, all of the holes on the tank wall will be precut on the workshop, instead of on the job site.

According to the size of the hole, there will be some flanges nozzles along with.

Glass Lined Steel Anaerobic Digestion Tank Specifications Coating color dark blue, dark green, white, and customized

A standard steel plate size effective size 2400mm x 1200 m

Steel plates thickness 3mm - 12mm, depends on the diameter & height

Coating thickness 0.25mm - 0.4mm, two coatings internal and external

Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14

Adhesion 3, 450N/cm

Elastic same as steel sheet, around 500KN/mm

Hardness 6.0 Mohs

Service life >30 years

Spark test >1500 V

Permeability gas and liquid impermeable

Easy yo clean smooth, glossy, inert, anti-adhesion

Corrosion resistance excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds About Center Enamel Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia.

Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc.

international standards.

CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc.

applications.

Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc.

The superior product quality and prompt service gain us worldwide recognition.
