Climatic Temperature And Humidity Test Chamber For Automotive Component Testing - China

Climatic Temperature And Humidity Test Chamber For Automotive Component Testing Introducion: Reliability test for prouduct Temperature&Humidity Chamber (climatic test chamber) can simulateanenvironmentand create effects in a range of temperature and humidity coditionsfor the purpose of testing the reliability of a prouduct or material.

Widely used in Automotive industry such asECU/electric part, PCU/inverter, Alternator/ISG, Moter or otherVehicle Components.

Make your own chamber with a variety of options Extended choice of options fitted to your testing.

Select your chamber from the door, refrigeration system, instrumentation, size! Order only what you need.

Technical parameter: - - - - Model | KMH-Series | 150R | 225R | 408R | 800R | 1000R | 150L | 225L | 408L | 800L | 1000L | 225S | 408S | 800S | 1000S | System | Balanced & Humidity Control System | Temp.

Range | -20~150 | -40 ~+150 | -70~+150 | Humidity Range | 20~98%R.

H | Temp.

constancy | 0.5 | Humidity constancy | 2.5%R.

H | Temp.

uniformity | 2.0 | Humidity uniformity | 3.0%R.

H | 5.0%R.

H | 3.0%R.

H | 5.0%R.

H | 3.0%R.

H | 5.0%R.

H | Heat up time | -20~+100 Within 35 mins | -40~+100 Within 45 mins | -70~+100 Within 60 min | Pull down time | +20~-20 Within 45 mins | +20~-40 Within 60 mins | +20~-70 Within 75 mins | Interrior material(CM) | W | 60 | 70 | 70 | 100 | 100 | 60 | 70 | 70 | 100 | 100 | 70 | 70 | 100 | 100 | H | 60 | 70 | 75 | 100 | 100 | 60 | 70 | 75 | 100 | 100 | 70 | 75 | 100 | 100 | D | 46 | 48 | 80 | 800 | 100 | 46 | 48 | 80 | 800 | 100 | 48 | 80 | 800 | 100 | Exterrior material(CM) | W | 88 | 98 | 98 | 128 | 128 | 100 | 100 | 110 | 150 | 150 | 100 | 110 | 150 | 150 | H | 173 | 189 | 194 | 216 | 216 | 160 | 175 | 185 | 200 | 200 | 175 | 185 | 200 | 200 | D | 140 | 146 | 174 | 175 | 195 | 98 | 108 | 128 | 128 | 148 | 108 | 128 | 128 | 148 | Interior material | Stainless Steel Plate(SUS 304) | Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | Refrigeration system | Air Cooled( Water Cooled Type is option) | Hermetic compresssor, refrigeration system | Hermetic Compressor, Cascsde Refrigeration CFC free refrigerant (HFC-507/HFC-23) | Controllor | LCD Toch panel, Chinese or English display selectabile Operation model /Program or fix point rinning Memory capacity, 120programs, 1200steps, all repeat999cycles, part 99 cycless.

| PID Parameter 9set Accuracy /Temp: 0.1%of F.

S1 dight Input /Temp: Pt-100/Humidity: Pt -100or1~5VDCV Comm.

Port RS-232C or RS-485 (Software is option) | Safety Devices | No fuse breaker, over pressure, over heat and over current protectors for compressor, over temp.

protector, over load protectorof fan, dry heat pr techto | Standard Accessories | Sightwindow*1, cable port(port50mm)*1, shelves*2, chamberlamp*1, power cable 2m | Weight(Kg) | 240 | 280 | 400 | 500 | 580 | 250 | 300 | 420 | 530 | 600 | 330 | 450 | 550 | 650 | Ambient Temp.

| -5~+35 | POEWR | AC 38010% 50Hz 3 phase 4 wires+Groud Wires | - - - - After salesservice: One year international warranty andforever technique service.

Wehas perfect quality assurance system and perfect warranty servicemeasuresand provideon lineprofessional servicesfor you!
