100l 3 Zone Thermal Shock Test Temperature Cycling Chamber Water Cooled - China

100L 3 Zone Thermal Shock Test Temperature Cycling Chamber / Thermal Test Chambere 1 - Application of thermal shock chamber: 1.1 Application: is used to test the bearing extent of the material structures and composite material in an instant and continuous high temperature and extremely low temperature environment, that is in the shortest time to test its thermal expansion and contraction caused by chemical change or physical harm.

Application objects, including metal, plastic, rubber, electronics .

and other materials can be used as a basis to improve their products or reference.

1.2 Corresponding standard: ISO 9001: 2000; ISO 9001: 2008; QS-9000; ISO 14001: 2004; CE, SGS, SMC, CMC, CPA, CE, CMA, IMC 1.3 # # Perfect appearance and easy to operate.

# Imported LCD English microcomputer temperature controller, with high memory capacity, can save 100 programs, max 9999 cycles, each cycle max time 999hrs.

# Two chamber structures, high temperature chamber and low temperature chamber, control automatically, stay and switch time adjustable.

# Perfect protection alarm functions: short-circuits, Leakage, over temperature of work chamber; compressor over pressure, over load, short water # Control interface will display alarm reason and provide check methods, machine has emergency stop button.

# Cold and hot shock temperature recover within1 minute, which complies with MTL, IEC, JIS, GJB and other international standards.

2 - More Info About KOMEG's Products You Need to Know 2.1 Refrigeration system characteristics The equipment is divided into high temperature zone, low temperature region, the three parts of the test area, the body of each zone by thermal unique structure.

Can choose the starting position, high or low temperature cycling.

Using color touch crystal display controller, simple operation, easy to learn.

High formula memory capacity can be set to 120 patterns.

The maximum cycles setting is 9999 - The maximum setting time of each pattern is 9999Hrs 59 minutes.

The machine is divided into three sections: the high temperature chamber, the low temperature chamber, and testing chamber.

2.2 Structure Features Wall material: Top-grade Carbon Steel Plate, Surface electrostatic color Spray processing Inner wall material: Stainless Steel Plate SUS304 Body insulation material: Rigid polyurethane Foam + glass fiber Door insulation material: Rigid Polyurethane Foam + Glass fiber 2.3 Material: Interior material: Stainless Steel Plate SUS304# Exterior material: Baked Painting Steel Plate or Stainless Steel SUS304# Insulation material: Rigid polyurethane Foam and Glass Fiber Wool 4 - Specifications - - - - Model | - - - - Thermal shock test chamberTST-A Series | - - - - | 70A | 130A | 226A | 360A | 500A | Test weight(KG) | 5 | 5 | 5 | 5 | 10 | Interior size | W(mm) | 410 | 520 | 610 | 710 | 810 | H(mm) | 560 | 670 | 770 | 830 | 710 | D(mm) | 410 | 520 | 610 | 770 | 860 | Basket size | W(mm) | 300 | 410 | 510 | 610 | 710 | H(mm) | 300 | 410 | 510 | 730 | 610 | D(mm) | 300 | 410 | 510 | 510 | 730 | Low Temp.

chamber | -55C-10C | Pre-cooling time | +20C-55C, Within 60 min | Test.

chamber | -40C+150C | High Temp.

chamber | +60C+200C | Pre-heating time | +60C+200C, Within 25 min | Recovery time | High-Temp Exposure 30 min | Low-Temp Exposure 30 min | Recovery time within 3 min | Standard accessory | Cable port(port50mm)*1, shelves*2 | Interior material | Stainless steel plate(SUS 304) | Exterior material | Baked painting steel or stainless steel(SUS304) | Insulation material | Rigid polyurethane Foam+glass fiber wool | Refrigeration system | Water Cooled | Semi-hermetic compressor, cascade refrigeration system, CFC free refrigerant(HFC-507 and HFC-23) | Controller | Panel: 7-inch LCD Touch panel, Chinese or English display selectable | Operation model: Program or fix point running | Memory capacity: 120programs, 1200steps, all repeat 999cycles, part repeat 99 cycles.

| Accuracy: Temp: 0.1% of F.

S1 digit Humidity: 0.1% of F.

S1 digit | Input: Temp: pt-100 Humidity: pt-100 or 5V DCV | Ambient Temp.

| +5C+35C | Power | AC 38010 50Hz, 3 phase 4 wires +Ground Wires | Note: 1 - We reserve the right to change specifications without prior notice 2 - Customized sizes and configurations available | - - - - 5 - About thermal shock test chamber: 6 - Tradeshow 7 - Company Culture
