400a Electronic Speed Controller Powers Your Rc Cars In Any Conditions - China

High power speed controller for ultimate handling experience 1 - Current: Continuous current 400A, peak 800A

2 - Output: 6-12s Li-Po

3 - Motor: BLDC Sensored or sensorless brushless motor

4 - Speed: <240, 000RPM

5 - BEC: 6.0V, 7.4V, 8.4V, continuous current 10A, peak 25A

6 - Bluetooth Communication: Parameter setting, firmware upgrade

7 - Mobile App: for quick programming, no need of additional modules

8 - Compatible with any RC motors

9 - Dimension: 127.5*81.0*59.5mm E3 electronic speed controller is a powerful product which is engineered for enthusiasts’ RC cars and trucks.

Six months ago, a notable RC car brand contacted us and consulted about technical problems.

They wanted to develop a most powerful electronic speed controller ever in RC car industry.

Comparing to existing products, E3 is really a power monster.

E3 is high performance with 400A continuous current, 6-12S Lipo, 16-54v power system, as I know, maybe it’s the most powerful motor controller (electronic speed controller or ESC) adopting to sensored or sensorless brushless motor, and supporting 240, 000RPM maximum.

BEC power is optional (6.0V, 7.4V, 8.4V), providing 10A continuous current, you can select it according the servo specification.

We know that thermal management is important to a powerful electronic device.

We design the frame meticulously.

With the combination of forged Al case and fin fan, E3 allows max airflow throughout the part to cool critical component down, promoting thermal performance to a new level.

With epoxy potted, waterproof design will protect electronics and promote heat dissipation in all weather conditions.

Fan is controlled intelligently by ESC.

When the internal temperature of system exceeds 55 Celsius Degree, the fan will be turned on, otherwise, the fan will be turned off.

If there is an abnormal heavy current, the ESC will cut off the power to fan, and the ESC will work normally.

Many parameters related to handling can be adjusted by mobile app via Bluetooth communication, such as running mode, number of Li-Po cell, cutoff voltage, throttle rate, braking force, turbo timing, initial PWM, etc.

and firmware can be managed on app as well.

Power is one thing, the most important is how can we control it perfect to avoid negative impact? We have designed many protection measures including low voltage, throttle loss, abnormal braking, over temperature, short circuit to fan, and so on.

We need performance, also we need safety.

We have been staying focused on design and manufacture of electronic speed controller for 13 years, serving top clients in their industries.

Parts are certified by CSIPER25, ISO11452-2, ISO10605, ISO16750, ISO7637 - We provide a full service from design, analysis, testing to supply, you don’t need to worry about the quality and reliability.

Have a try, contact us or google Shenzhen Xiongcai Technology for detail.

If you have any special concept or requirement, we will help you achieve your ideas.
