Portable Sd Hd Fiber Optic Transceiver 12v Dc Support 1080p With Hdmi Port - China
price: check with company for price
Portable SD / HD Fiber Optic Transceiver 12V DC Support 1080P With HDMI Port 1 - Overview Newbridge ND6210B converter is an equipment which is exclusive using in converting single channel SDI signal to HDMI signal .
It integrates SDI transmitter and HDMI demodulator which conveniently converts SDI signal to HDMI signal, at the mean time, it will separate and convert SDI signal s audio signal, and then it will embed it to HDMI signal synchronously to realize the video and audio transmitting synchronously.
The device is designed to be able to controlled switch, User can choose HDMI output or DVI output by it.
in the mean time, this equipment has one channel loop back function in SDI signal output, User can monitoring expediently in this locality.
2 - Features - - - - ND6210B | l Support SDI input format: 480i, 576i, 720p30/50/60, 1080p24/25/30, 1080i 50/60, 1080p50/60 - # Support SMPTE 425M(A level and B level), SMPTE424M SMPTE292M, SMPTE259M-C.
# Carry 1 channel SDI signal looping out.
# SDI signal support the maximum input coax length: Belden 1694A: SD-SDI 400m; HD-SDI 200M; 3G-SDI 140M # Automatically embed SDI audio signal to HDMI signal.
# HDMI port support digital DVI signal.
# Can choose HDMI output or DVI output # Automatically detect the HDMI EDID information adaptive HDMI best mode | - - - - 3Application Diagram 4 - Dimensions 5 - Specifications - - - - Model | NB6210B | Input Interface Type | 1x BNC SDI | Input Signal | SD-SDI (270Mbps), HD-SDI (1.485Gbps), 3G-SDI (2.97Gbps) | Support Input Format | SD: 525i @ 59.94Hz, 625i @ 50Hz HD: 720p @ 23.98/24Hz/25Hz/29.97Hz/3 0Hz/50Hz / 59.94Hz / 60Hz 1080i @ 50Hz / 59.94Hz / 60Hz 1080p @23.98Hz/24Hz/25Hz/29.97H z/30Hz 3G: 1080p @ 50Hz / 59.94Hz / 60Hz | SDI Signal Range | 0.8V p-p | SDI Impedance | 75 ohms | SDI Coupling Type | AC Coupling | Max.
Input Coax Length | Belden 1694A SD-SDI 400m / 1300ft ; HD-SDI 200m / 600ft ; 3G-SDI 140m / 450ft | SDI Loop Out Interface | 1x BNC SDI | HDMI/DVI Output Interface | 1x HDMI | Frequency Bandwidth | 165MHz/ up to standard with HDCP : HDMI 1.3 | Power Supply | 5~24DC | Power Consumption | 3~5 Watts | Operating Temperature | -10C ~ 60C / 14F ~ 140F | Storage Temperature | -30C ~ 70C / -22F ~158F | Relative Humidity | 20~90% RH (Non-condensation) | Dimension | 112x 117x 25 mm / 4.40x 4.46 x 0.98 inches | Weight | 280g | - - - - 6 - Order Information - - - - Part No | Description of product | Unit | ND6210B | SD/HD/3G-SDI to HDMI Converter | pcs | - - - -
