Bottom Cable Exit Adjustable Wire Gripper Nickel Finishing With M 10 Male Thread - China

Bottom Cable Exit Brass Cable Grippers Nickel Finishing With M10 Male Thread This cable gripper has a Key flange at top, With a male thread of M10*1, the thread length is 15mm.

It's best suited to indoor applications with small diameter wires 1.0~1.2mm.

Other sizes and styles can be supplied as well, Contact us for your requirements, or send us your drawing for OEM.

Cable Gripper Design Within each cable gripper is a plunger that a cable slides through.

There are three balls that surround the outside diameter of the cable as it passes through the gripper.

When weight is applied to the gripper when mounted, the tension forces the balls to grab the cable in a pinching movement.

In normal operation the more the tension, the more the gripping.

Some grippers come with a safety nut that locks the movement in both directions eliminating the potential for a release if the plunger is accidentally depressed by an end user.

They can be repositioned without damaging the cable and no tools are necessary.

Just push and slide it.

One hand is sufficient - the grippers are installed wholly without tools and are infinitely adjustable.

If you have a project that involves unusually sloped, curved or high ceilings, our aircraft cable gripper system may be the solution for you.

It is affordable, flexible and easy to install.

To find out more about this more solutions for your hanging system, Please feel free to contact our sales team.

Description - - - - 1 - Material | Brass | 2 - Size | 12*17mm /Customized | 3 - For use with Cable | 1.2~1.5mm | 4 - Finishing Color | Nickel plated;Customized | 5 - Application | With our many adjustable Cable Gripper styles you can hang anything: Light Fixture Pendants, Signs, Displays, Drop Ceilings, Shelves, Picture Frames and more.

| 6 - Safe Working Load | 20KG, depends on the cable diamter work with | 7 - How It Works | Adjustable Cable Grippers are sophisticated in design but simple to use: Insert the cable into the plunger and slide the gripper to the desired position.

Where it stops it locks.

To re-adjust, simply depress the plunger with your fingertip and move the gripper to a new position.

Release the plunger to lock.

The 3--ball gripping mechanism is spring-loaded and allows the gripper to move freely up the cable.

It cannot move down unless the plunger is depressed.

While there is any weight at all on the gripper, the plunger cannot be depressed.

An optional safety nut or safety cap can be added to completely lock the mechanism in both directions.

The greater the weight, the stronger it grips.

| - - - - Advantages: 1 - The adjustable cable grippers offer a secure and elegant solutionfor any fine art installation, as well as Lighting Products, Signs, Dispalys, Graphics and many other items; 2 - Radically reducing installation time and eliminating human error; 3 - Easy to adjust cable length, easy to release; 4 - Low cost and competitively priced for use in industrial and architectural lighting applications; 5 - Perfect for Suspend Signage + Lighting Systems + Suspended Fixtures; 6 - Supplied as Gripper Only or Gripper with Cables in different length.

FAQ PriceTerms: FOB Price: For ocean shipment, FOB Shenzhen; EXW: Exclude all the freight cost, delivery in factory of Yingwei; Both the prices exclud taxes, as well as shipping and handling charges.
