4×8 Mechanical Optical Switch - China
price: 1000.00 Dollar US$
XH-OSW-4×8 mechanical optical switch is a kind of light path control equipment.
It can realize multi-channel fiber optic light path switching.
In the optical fiber transmission system, it is used for multi-channel fiber monitoring, multi light source/detector selection, and optical fiber path protection etc.
Besides, it is also used in optical fiber test system for optical fiber and related component test, outdoor cable test and multi-spot optical sensors monitoring system.
Feratures Low Loss and High Reliability
Serial Interface (RS-232) Modularized Design
Epoxy-free on Optical Path
Applications Ring Network
•Remote Monitoring in Optical Network
•Testing of FiberOptical Component
Specifications Parameter Parameter Values
Model XH-OSW-4X8-N
Insertion Loss ≤1.5 dB
Wavelength Range 1260~1650 nm
Fiber Type 9/125um
Return Loss ≥50 dB
Crosstalk ≥ 55 dB
PDL ≤0.10 dB
WDL ≤0.30 dB
TDL ≤0.30 dB
Repeatability ≤0.05 dB
Lifetime >107
Switching Time ≤20 ms (Adjacent channel)
Connector LC/UPC
Control Mode RS-232
Working Power Supply 5V/800 mA
Product Sze 135x64x32
Operating Temperature -20 ℃ to +70 ℃
Operating Temperature -40 ℃ to +85 ℃
Company Contact:
- Phone: 8607713121055
- Address: Room 3-3, No. 17 MingYang Fifth Road, MingYang Industrial Area, Wuxu Town, Nanning, China
- Email:
- Website: https://www.xhphotoelectric.com
Published date: July 4, 2023
- Business Description: Optical Switch, OLP, optical-power signal acquisition equipment, VOA, stable optical sources, wavelength division multiplexers, circulators, optical fiber collimators, optical fiber jumpers, optical cable monitoring systems, distributed optical fiber temperature measurement systems (DTS),FBG sensors optical fiber grating sensors and other optical communication products.
