Series H4 Led Low Bay Light - China

Suspended 80w modular design led low bay lighting

series h4 led low bay light

model：

zgsm-gcd80h4

application：

warehouse | workshop | garage | billboard | area | building led high bay lighting

key features

1 - wide power range: 40w~360w.

2 - special circuit design, single led’s damage won't affect others' normal work.

3 - modular design for easy installation, replacement and maintenance.

4 - high lumen output up to 165lm/ w with high quality led chips.

5 - various applications with different mounting accessories.

6 - multiple lighting control options are available, e.g. dali, 1-10v, motion sensor.

7 - designed to last at least 100, 000 hours at l70.

8 - multiple lighting distributions are available.

we also provide led gas station canopy lights, ul certified led high bay light, garage led high bay light, 300w led flood light and soon.

zgsm is a hi-tech and private enterprise devoted to r&d, producing and selling of economical led street light, building led high bay light, lithium battery solar power system and so on.

as specifications

model zgsm-gcd80h4

led brand lumileds luxeon 3030/5050

driver brand meanwell hlg series

norminal wattage 80w

led module quantity 2 modules

input voltage 100-240/277/347/480vac


power efficiency >90%

power factor >0.95

lamp rated luminous efficiency 140-165 lm/w

lamp rated lumen output 11200-13200 lm (lumen tolerance +/- 5%)

color rendering index 70 (80 is optional)

color temperature 3000k, 4000k, 5000k or 5700k

photometric type 60, 90, 110 degrees

optimal operating temperature 25℃

storage temperatures -40°c~50°c

working environment between-40°c~+50°c, 10%~90%rh

total harmonic distortion < 10%

lumen maintenance > 100, 000 hours -l70, @25 ºc (77 ºf)

body die-cast aluminum housing

cover pc lens

rating ip66 ik10

protection class i ( class ii optional)
