Copper Rod D17mm D30 Upcasting Upward Continuous Casting Machine Annnual 2000mt - China
price: check with company for price
Upcasting process oxygen free copper rod 10mm upward continuous casting production line Equipment Composition Electrolytic copper plate (cathode copper/99.9% copper scraps) -- charging device (can match) - furnace system (melting furnace -- transition warehouse - holding furnace) - [continuous casting machine] crystallization moulding) -- dragger - speed device - automatic winding machine - for sale or deep processing Flow Chart Electrolytic copper plate (99.9% copper scraps) is joined in the melting furnaces through the charging device (according to the user needs), (if the raw materials is not 1# red copper, our company can design and install the reverberatory furnace before melting furnaces to remove the copper impurity).
The copper plate through W-type inductor into liquid, then flow smoothly from the transition storehouse to the holding furnace, and then is in the steady reduction process through the surface covered with charcoal, at last is crystallized swiftly to the cast copper rod by the [crystallizer]of the [upcast plant] by [upward copper rod process] at the same time, [cast copper rod] is [upward casted ]intermittently through the two traction roller.
The [cast copper rod] through the hauling machine, and the wheelframe, the speed adjusting gear, then to the automatic winding machine to wind copper rod.
Main Technology Parameter For Copper Rod Up-casting Machine - - - - Annual 2000MT D17mm-30mm | Model: HDSYUCM-2000 | Yearly capacity: 2000mt | Furnace structure : 300type two- body furnace ( 1 - melting furnace2 - holding furnace) | Casting strands: 4 | Casting rod diameter: 17mm 30mm | casting speed: 0lOOOmnVmin | annual working time: 7920h | Liquidtracking precision: 2mm | Take-up coil standard;
Company Contact:
- Phone: 86-510-83788308
- Address: Xishan district,Bashi Industrial Park,Wuxi City,Jianggsu Provice, Wuxi , Jianggsu , China
- Email:
Published date: April 11, 2018
- Business Description: Our company is a comprehensive enterprise integrating scientific research, development, equipment installation and sales & services.
Our company is dedicated to professional manufacture the production lines for casting of various non-ferrous metals and heat treatment since 1989.
