Ultra Thin Indoor Full Color Led Display 320mm 160mm Wide Viewing Angle High Refresh Rate - China

SMD P5 Inddoor LED Dispaly 320mm*160mm Low Price Good Quality Brightness 1000 Product Features:

# # Support Seamless Splicing of Inner Arc and Outer-arc

# Support both Inner arc and outer-arc splicing.

For installation, minimum outer-arc 10 degree, maximum inner arc 10 degree.

# Super thin and light die-casting aluminum panel 500*1000*75mm, only 13 kg/panel ;

# High precision technology, can achieves seamless combination ;

# High flatness with SMD leds, accurate to 0.1mm ;

# Fanless design, its completely quiet ;

# Fast installation and dismantle with fast locks ;

# Front service structure design, with front service tool, you can do the replacing youself easily.

# Black SMD leds with high conrtast ratio, good color uniformity ;V Product Parameter: - - - -

ITEM | SPECIFICATION | Pixel Pitch | 5mm | Pixel Density | 40000 dots/sq.

m | Pixel Configuration | 1R1G1B | Pixel Type | SMD3528 | Module Size | 320*160mm | Module Resolution | 64*32 pixels | Drive Mode | 1/16 scan, constant current | Brightness | 1500CD/SQ.

M(adjustable) | Refresh Rate | 1200Hz | Frame Frequency | 50&60Hz | Grey Scale Level | 65536(adjustable) | Color Temperature | 3200~9300K(adjustable) | Contrast Ratio | 4000: 1 | Viewing Angle | 150(Horizontal), 120(Vertical) | Best Viewing Distance | 5~50m | Brightness/Color Uniformity | 97% | Cabinet Flatness | 0.2mm | Protection Level | IP31 | Power Consumption (Max) | 700W/M2 | Power Consumption (Avg) | 250W/M2 | Voltage | AC 100V~240V, 50/60 Hz | Control System | Synchronous/Asynchronous Control System | Input Signal | RF, TV, S-VIDIEO, RGB, VGA, DVI, HDTV, PAL, YUT, YC, COMPOSTITION | - - - - - - - -

Cabinet | Dimension | 640mm*640mm | Monomer Module Number | 16pcs | Power supply | 5V/40A*2pcs | Thermal discharge | fan 2pcs | Pixel per cabinet | 128*128 | Best viewing distance | 5M20M | Best viewing angle | 110(W) 110(H) | Temperature | storage: -35+85

working: -20+50 | Relative humidity | 10%-95% | Thickness | 85m | - - - - Project Case:

s
