P F Inductive Sensor Nj1 5 Pd Us 1 250 V93 - Germany
price: 298.00 Dollar US$
Inductive sensor NJ1.5-PD-US-1.250-V93
2-wire AC/DC
Weld Immune
Sensing range 1.5 mm
3000 psi rating
Product Description
Proximity switch
General specifications
Switching element function AC/DC NO
Rated operating distance 1.5 mm
Installation flush
Output polarity AC/DC NO
Assured operating distance 0 .
1.21 mm
Reduction factor rAl 0.4
Reduction factor r304 0.85
Nominal ratings
Operating voltage 20 .
250 V AC/20 .
300 V DC
Switching frequency 0 .
20 Hz
Hysteresis 10 .
20 typ.
15 %
Reverse polarity protection yes
Short-circuit protection yes
Voltage drop ≤ 7 V
Momentary current
(20 ms, 0.1 Hz) max.
3 A
Operating current 8 .
300 mA
Off-state current < 1.7 mA
Mag.
Field strength, AC fields 250 mT
Mag.
Field strength, DC fields 100 mT
Limit data
Operating pressure dynamically 3000 psi
Indicators/operating means
LED green Power on
LED red Output status
LED red/green Short circuit/overload indication
Standard conformity
Standards EN 60947-5-2
Approvals and certificates
UL approval cULus Listed, General Purpose
CSA approval cCSAus Listed, General Purpose
Ambient conditions
Ambient temperature -25 .
70 °C (-13 .
158 °F)
