High Switching Coil Latching G5rl K1a E Dc12 - India

price: contact company for price

16A High Switching Current SPST Dual Coil Latching Relay - G5RL-K1A-E-DC12

FEATURES:-

• Low profile: 15.7 mm in height.
• Creepage distance 8mm between coil and contacts
• 10 kV Impulse withstand voltage
• Models with AC coil available.
• High-Inrush model available (Inrush peak currents up to 100 A)
• Low Noise models available (Approx. 10 to 20 dB less sound pressure than standard G5RL-Series Relays)
• TV8 Rating models available (TV8 for UL standard)

APPLICATION:-

• Housing equipments
• Audio-visual products
• Office automation machines
• Air-conditioners
• Lighting

DESCRIPTION:-

Manufacturer: Omron
Product Category: General Purpose Relays
RoHS: RoHS Compliant
Product: Power Relays
Type: High Capacity
Coil Voltage: 12 VDC
Contact Form: SPST (1 Form A)
Contact Current Rating: 16 A
Contact Termination: Solder Pin
Mounting Style: Through Hole
Switching Voltage: 250 VAC, 24 VDC
Coil Termination: Solder Pin
Coil Type: Dual Coil Latching
Coil Resistance: 192 Ohms
Coil Current: 62.5 mA
Contact Material: Silver Alloy (Ag)
Brand: Omron Electronics
Height: 15.7 mm
Length: 29 mm
Maximum Switching Current: 16 A
Packaging: Bulk
Series: G5RL-K
