Hengxiang Kn40 Series External Diameter 40mm Thickness 20mm Hollow Shaft Servo Motor Encoder - China

price: 30.00 Dollar US$

Hengxiang Kn40 Series External Diameter 40mm Thickness 20mm Hollow Shaft Servo Motor Encoder

Products Photos Catalog Hengxiang Kn40 Photos Catalog

KN35- Series hollow shaft Encoder Specification Brand: HENGXIANG

External Dimensions: External diameter: 35mm of servo motor encoder

Thickness: 18mm

Shaft diameter: 6mm/8mm/9mm/9.52 mm/10mm

Multi axis optional encoder

Resolution ： 1024;2048;2500;3600;5000; 7200;10000;14400

1000/6; 1000/8; 1024/6; 1024/8; 2048/6; 2048/8; 2500/6; 2500/8 high-precision encoder Output Phase：Phase A, B, Z, U, V, W, Supply voltage：DC5V & DC8-30V

Outlet type：Cable out from side

Output Mode：Collector open circuit output(NPN &PNP)

Voltage output：Line Driver (26LS31)；Line Driver ( 26C31)；Line Driver(IC-HD7)

Environmental temperature Operating temperature: -20~+100° (Non icing)

Storage temperature: -25~+110° (Non icing)

Environmental humanity Operating and storage: 35~90%RH (non-condensing) Protection grade：IP40

Cable length：500mm (cable length could be added ) from mini encoder

Shell： Aluminium for Robust encoder

Package：Carton box

Net weight：About 90g (with package) of Portable encoder Certification： CE for Reliable encoder


Company Contact:


  • Phone: 15956966023

  • Address: R301,Building7,Lane 115,No.1276 Nanle Road,SongJiang, shanghai , China

  • Email: Email


Published date: June 12, 2017

  • Business Description: We are specializing in the production of encoders, with more than 16 years of experience, we could provife you solid shaft encoder/ hollow shaft encoder/ absolute encoder and so on.
