Ge Ds200rtbag2afb Relay Terminal Board - China

GE DS200RTBAG2AFB Relay Terminal Board Basic Information Brand: GE (General Electric) Model：DS200RTBAG2AFB Type: Relay Terminal Board Technical Specifications and Features Design: The DS200RTBAG2AFB is a Relay Terminal Board (RTBA) designed for General Electric's Mark V board series and can be used for a wide range of GE brand drive and exciter applications.

Number of Relays: By installing this board into the drive cabinet, an additional ten relays can be provided to the user.

Relay Types: Includes both DPDT (double-pole, double-throw) and 4PDT (four-pole, double-throw) types of relays.

the DPDT type includes seven relays on the card (K20 through K26), each with two C-type contacts rated at 10A.

the 4PDT type includes three relays (K27 through K29), each with four C-type contacts rated at 1A.

Protection: All ten relay points are protected by a 130 VAC metal oxide varistor (MOV) to ensure circuit safety.

COILS: Each relay contains an internal 110 VDC coil to ensure that they will function properly.

PLUGGABLE CIRCUITS: There are two plug connectors on the face of the board, including a CPH plug connector for the positive side of the pluggable circuit control power supply and a CPN plug connector for the negative side of the circuit control power supply.

Position Identification: Positions K20 to K29 are the board positions for all on-board relays for easy connection and configuration.

Application Scenarios and Uses Industrial Automation: DS200RTBAG2AFB relay terminal boards can be used in a variety of industrial automation systems in areas such as power, oil and gas, water treatment, manufacturing and transport.

Control Systems: As a member of the Mark V board series, this relay terminal board can be used in a variety of control systems to provide additional relay functions to meet the system's needs for signal transmission and control.
