Coupled Mosfet Igbt Gate Drive Transformer Fa2659 Al 0 5 8 W Output - China

FA2659-AL Gate Drive Transformer For Coupled MOSFET and IGBT Gate Drive Circuits Product description: Gate Drive Transformer Designed for transformer coupled MOSFET and IGBT gate drive circuits Feature: # Designed for transformer coupled MOSFET and IGBT gate drive circuits; operatingfrequency: 50 kHz to 2 MHz.

# 2250 Vdc, one minute primary to secondary isolation # Requires only 56 mm2 of board space.

# Core material Ferrite # Terminations RoHS compliant tin-silver over tin over nickel over phos bronze # Weight 700 mg # Ambient temperature 40C to +125C # Storage temperature Component: 40C to +125C.

# Tape and reel packaging: 40C to +80C # Resistance to soldering heat Max three 40 second reflows at +260C, parts cooled to room temperature between cycles # Moisture Sensitivity Level (MSL) 1 (unlimited floor life at <30C / 85% relative humidity) # Failures in Time (FIT) / Mean Time Between Failures (MTBF) 38 per billion hours / 26, 315, 789 hours, calculated per Telcordia SR-332 # Packaging 175/7reel; 750/13 reel Plastic tape: 24 mm wide, 0.4 mm thick, 12 mm pocket spacing, 7.0 mm pocket depth - - - - Part number | Turns ratio pri : sec | Primary inductance 20 % (mH) | Leakage inductance max (H) | Primary DCR max (Ohms) | Secondary DCR max (Ohms) | Volt-time product (V-sec) | SRF min (MHz) | Capacitance pri to sec max (pF) | FA2659-AL | 1 : 1 | 296.0 | 1.5 | 0.795 | 0.655 | 34.2 | 1.39 | 21.9 | - - - - 1 - Inductance measured at 100 kHz, 0.1 Vrms, 0 Adc 2 - Leakage inductance measured at 100 kHz, 0.1 Vrms with secondary pins shorted.

3 - SRF measured with coils connected in series using an Agilent/HP 4192 or equivalent.

4 - Operating temperature range 40C to +125C.

5 - Electrical specifications at 25C.

FA2659-AL Gate Drive Transformer For Coupled MOSFET and IGBT Gate Drive Circuits Shape and Dimensions: Product Picture: FA2659-AL Gate Drive Transformer For Coupled MOSFET and IGBT Gate Drive Circuits HOW TO ORDER 1 - Please send me your datasheet or part number you need.

2 - We will offer the replacement quotation for your reference 3 - The free samples are available for your approval.

4 - After sample testing, we will step into the mass order.

5 - The Proforma Invoice will send for your confirmation 6 - After the goods finished, we send the goods to you and tell you the tracking number.

7 - We will track your goods until you receive the goods.

Remarks: 1 - Sample orders are avaliable.

2 - Price is negotiable for orders of large quantity.

3 - Customized orders (OEM/ODM orders) are avaliable.

4 - Contact us for available flavors list.

International Certifications: 1 - ISO9001: 2008 2 - UL 3 - Reach 4 - RoHs Our service: 1 - 100% tested before shipping 2 - Have alternative for Halo, Pluse, Wurth, We-online, Chilisin, CoilcraftSame quality but better price 3 - Free sample available 4 - Provide new design for customer
