Automatic Screwing Tightening Fastening Machine For Fire Row Burner - China

Features:

1)Adopt the design of double slipping station, The left and right station can work in turn without interference from each other.

2)Aim at the matter of discordant distance between the front and back thread hole of fire row burner, We adopt the high precise CCD camera to position, Which can ensure the success rate of assembly stable at more than 99.9%.

3)This set automatic screwing machine for fire row burner can realize natural gas injector feeding, seal ring feeding and injector fastening at the same time, Which can improve the assembly efficiency much.

4)Huge screw feeder can hold 2000~2500 pcs of natural gas injector one time.

So you should never need to worry the matter of lacking screws during production any more.

5)Equipped with the LED touch screen which can display the alarm in real time, So it is very convenient for operator to find and solve the problem in a short time.

6) The machine owns the function as the following: Quantity statistics(OK amount and NG amount), thread slip detection, floating detection, screw omission detection etc.

7) Adopt the ASA brand electric screwdriver especial for automation as the driver, Torsion outputs stably, Which can ensure a perfect assembling quality.

8) Universal power supply: 110-240ACV, 50~60Hz.

Model and specification:

Model ENC-SA400DS

Production efficiency 3~4 pcs/Min.

Universality 2 types (Model one and model two)

Power supply 110~240ACV, 50~60Hz

Dimension 1200x2140x2200 mm

Weight 450 kg

Screw driver type ASA electric screwdriver (For automation application only)

Capacity of vibration bowl 2000~2500 Pcs

Torque 25 kgf/cm²

Automation level Semi-automatic type
