Adjustable Brightness Outdoor Smd Led Display Low Power Consumption For Media Advertising - China

P10 Outdoor SMD led display high refresh rate full color led advertising screen Specifications 1 - p10 outdoor full color led display 2 - High refresh rate: >600hz 3 - High brightness: >8500cd/2 4 - 2 years warranty Features: 1) With good lightening accordance and no mosaic 2) Led advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment 3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced 4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment 5) Uses real pixels rather than virtual pixels, better viewing eff Parameter - - - - No | Item | Parameter | 1 | Pixel Pitch | 10mm | 2 | Pixel Configuration | 1R1G1B / R: G: B=3: 6: 1 | 3 | LED Lamp | Full color | 4 | Density | 10000dot/m2 | 5 | Module Size | 320*160mm | 6 | Module Pixel | 32*16=512dot | 7 | Module Thickness | 17mm | 8 | Module Weight | 395g | 9 | Module Power | 63W | 10 | Drive Valtage | DC5V | 11 | Module Electric Current | 11-12.5A | 12 | PortType | HUB-75D/B | - - - - - - - - No | Item | Parameter | 1 | Standard Caninet Size | 960mm*960mm*130mm | 2 | Cabinet Weight | 9.85KGS | 3 | Brightness/Adjustment | 7800cd/m, Level 16- Automatic / Level 100-Manual operation | 4 | View Angle | 120(Vertical), 120(Horizontal) | 5 | Best View Distance | 10-100m | 6 | Grey Scale | Within 65536 Step | 7 | Frame Frequency | 60Hz | 8 | Refresh Rate | 1560Hz | 9 | Signal Input Source | Composite, S-video, Component, VGA, DVI, HDMI, SDI, HD-SDI | 10 | Scan Mode | 1/2 1/4 | 11 | Drive IC | 5020 | 12 | Module Qty / M2 | 19.5 | 13 | Display Color Qty | 16777216 | 14 | Continuous Working Time | >24(Hrs) | 15 | Screen Lifespan | >100, 000(Hrs) | 16 | MTBF | >5000(Hrs) | 17 | Max.

power consumption | 1250W/ | 18 | Ave.

power consumption | 420W/ | 19 | Out of control pixel rate | 3/10, 000(discrete distribution) | 20 | Control Distance | 100M(Ethernet) 500M(Multi-fiber) 10KM(Sigle-fiber) | 21 | Flatness | Screen Surface0.5mm, Pixel Pitch0.3mm | 22 | Operation Temperature | -10+50 | 23 | Working Humidity | 10%98%RH | 24 | Storage Temperature | -40+85 | 25 | Software Connection | Standard Computer Connection, Compatiable With Windows, Unix, Novell | 26 | protection system | Overtemperature/overload/ power/image compensation/nonlinear correction | 27 | Working Valtage | 200~240 V | 28 | Dielectric Strength | 50HZ/1500V(AC RMS)/1min | 29 | Temperature Rise | Metal40K, Insulation65K, After Heat Balance | 30 | IP Grade | IP65 | 31 | Computer display mode | 1024*768 | 33 | Media Player | LED Pressional Media Player | - - - - Project Cases
