3000w Off Grid Pure Sine Wave Power Inverter - China

3000W Pure Sine Wave Inverter What is power inverter?

A power inverter, or inverter, is an electronic device or circuitry that changes direct current (DC) to alternating current (AC).

The input voltage, output voltage and frequency, and overall power handling depend on the design of the specific device or circuitry.

The inverter does not produce any power; the power is provided by the DC source.

Inverter features:

1 - With high reliability and low failure rate by using the advanced Double-CPU single chip intellectual control technology.

2 - Pure sine wave output.

3 - Small, light and artistic, benefited from adopting the SMD pastern technology.

4 - Cooling fan is intellectual controlled, and its working status is controlled by CPU, which mostly increased its service life and helps to save the power consumption, improve work efficiency and lower the working noise.

Applicable for:

·Solar electric energy generation.

·Wind power generation.

·Communication equipment.

·Industrial intellectual control system.

·Small sized emergency power supply system.

Main specification details:

Model PQ-3000H

Input DC voltage 12V 24V 48V 110V

Voltage range 10-15.5V DC 20-30V DC 40-60V DC 90-135V DC

No load current draw <2A

Efficiency >90%

DC connection Cables With terminal

AC connection Power line with plug

Output AC voltage 100/110/120V AC or 220/230/240V AC

Continuous power 3000W

Surge power 6000W

Waveform Pure sine wave

Frequency 50HZ or 60HZ

AC regulation 3%

The mains bypass output 100/110/120V AC or 220/230/240V AC

Protection Low voltage alarm 10.5V DC±0.5V 21V DC±0.5V 42V DC±1V 96V DC±2V

Low voltage shut down 10V DC±0.5V 20V DC±0.5V 40V DC±1V 90V DC±2V

Short circuit Shut off output automatically

Over load Shut off output

Over voltage shut down 15.5±1V 30±1V 60±2V 135±3V

Over thermal Shut off output automatically

Environment Working temperature -10ºC~+50ºC

Working humidity 20%~90% RH

Storage temperature -30ºC~+70ºC

Package Machine size(mm) 460*217*153

Packing size(mm) 550*300*230

Net weight(kg) 10.3

Gross weight(kg) 12.3

Packing mode Carton packaging

Other Start Soft start

Cooling ways Intelligent cooling fan
