1000v Mc4 Inline Fuse Holder Adapter 1 30a 1000 1500v Dc - China

price: 2.20 Dollar US$

1000v Mc4 Inline Fuse Holder Adapter 1 30a 1000 1500v Dc

Products Photos Catalog 1000v Mc4 Inline Fuse Photos Catalog

Quick Details

Place of Origin:

Zhejiang, China (Mainland)

Brand Name:

Solarson

Model Number:

MC4

Type:

Adapter

Application:

PV Energy System

Gender:

Male and Female

Rated current:

1-30A

Rated voltage:

1000/1500VDC

Certificate:

TUV CE

Waterproof grade:

IP68

Insulation material:

PPO Rated Current max 30A(1-30A) Rated Voltage 1000/1500V DC Test Voltage 8kv(50HZ, 1min) Contact Resistance Of Plug Connector 5mΩ Contact Material Copper, Tin-plated Insulation Material PPO Degree Of Protection IP68 Flame Class UL94-V0 Safety Class II Suitable Cable OD 4.5-8.5(2.5-6.0mm2) Insertion Force/Withdrawal Force ≤ 50N/≥ 50N Temperature Range -40 °C ~ +85°C(IEC)


Company Contact:


  • Phone: 13626533618

  • Address: Daidong Industrail Zone,Liushi, Yueqing , zhejiang , China

  • Email: Email


Published date: July 26, 2019

  • Business Description: Yueqing Aidun Electric Co.,Ltd was found by a experienced engineer team and excellent sales team ten years ago.

    The enterprise specializes in Design and manufacturing new energy products and low &high voltage products ,our main products is DC fuse ,DC Surge protector device DC circuit breaker ,MC4,solar cable and other low voltage and high voltage products our products used for solar photovoltaic system,power system,communication system,wind power generation and so on.

    Our brand is “Solarson”,our main purpose is supply more green new energy products ,Our company grows fast and now our company integrate design R&D advanced production equipment and professional management system.

    our products have got CE,CB,TUV,CCC,RoHS and other certificates.

    Excellent quality product with good price ,we have gain a lot customers in China ,Aidun Electrical also have rich experience of export,now our main market is European ,Southeast Asia,Middle East,,America and so on.
