Main Cable For Electric Bike - China

Main cable for electric bike electric scooter ebike wiring E Bike waterproof cable

Name 1st G Main cable

Model WYT-P-8~11AT

Inlet/Outlet 8～11 cores

Rated voltage 48V AC/DC

Rated current 2A

Withstand voltage 500V

Insulation resistance ≥20MΩ

Contact resistance ≤10mΩ

Mechanical life 200 times

Insertion force ≤80N

Pull out force ≥30N

Working temperature -25℃～+85℃

Protection grade IP66

Dimensions 11mm

Overalllength 70mm

Contact element material gold-plating Copper alloy

Wire specification 0.20mm²

RATINGS/CHARACTERISTIC S

UL Recognized

RoHS Compliant

48 V

8 to 11 Pins

MATERIAL

FEATURES

Most common signal connector, signal cable for Electric bike.

Lenght: can be any length needed.

Current: 2A

Life: 200 times

ENVIRONMENTS

Ebike throttle, Led dispaly, braker.

Electric scooter throttle, Led dispaly, braker.

signal cable, single connector for electric tools
