Ultra Low Power Consumption Dg21108 - China

Ultra-low power consumption DG21108

Product Usage: Household air conditioner

Power Consumption Characteristics: Ultra-low power consumption

LCD Product Type: STN

Perspective Features: Wide Angle of view

Temperature Characteristic: Wide temperature

Polarizer Type: Transmissive DG21108

1 - Boundary Dimension: 50.0*(41.0＋36.0)mm

2 - Strong Viewing Direction: 12 o’clock

3 - V-OP: 3.3V

4 - Drive Method: 1/4 DUTY; 1/3 BIAS

5 - Operating Temperature: -30℃~70℃

6 - Storage Temperature: -40℃~80℃

7 - Polarizer: Transmissive/Positive

8 - Display Type: STN YELLOW/GREEN

9 - Product Usage: Household Air Conditioner AC LCD Display Introduction

An air conditioner's LCD display is a screen that displays information about the current status and settings of the air conditioner.

This can include the current temperature, the set temperature, the current mode (e.g. cooling, heating, fan), and any error messages that may be present.

The ac LCD display is typically located on the front panel of the air conditioner, and is often accompanied by a series of buttons or a control panel that allows the user to adjust the settings of the air conditioner.

Some air conditioners also come with remote controls that allow the user to adjust the settings from a distance.

The air conditioner LCD display is an important feature of an air conditioner as it allows the user to easily see and understand the current status and settings of the device.

It can also alert the user to any issues or problems that may be present, such as a malfunctioning sensor or low refrigerant levels.

Overall, the ac LCD display is an important part of an air conditioner that allows the user to easily monitor and control the device.

Company Contact:

• Posted By: Dianguang Electronics Co., Ltd.

• Phone: 18931993788

• Address: 5/F Building B-2, Guanggu Science and Technology Park NO. 99 Yuyuan Street, Luquan Zone, Shijiazhuang , Hebei , China

• Email:

• Website: https://www.dgdz-lcd.com

• Business Description: Dianguang Electronics Co., Ltd. was established in 1986 - The company is located in Shijiazhuang, the capital of Hebei Province, which is one hour away from the capital Beijing.

  It is specifically located in the Optical Valley Science and Technology Park of Luquan Economic Development Zone, which is a hundred billion electronic information industry cluster.

  It is an early Sino-foreign joint venture under the Hebei Liquid Crystal Display Development Co., LTD. Besides, it is one of the early professional manufacturers of liquid crystal display (LCD) module (LCM) in China.

  Over the years, with the best pursuit of customer satisfaction and strong investment in technology and quality, Dianguang has created a new situation of technical cooperation and transaction with many well-known brand enterprises.

  The company's production base plant covers an area of 30,000 square meters.

  We has 2 full-automatic LCD production lines, 1 LCM automatic module production line and 1 COG automatic module production line.

  We also has completely advanced production equipment for electronic assembly of LCD, COB, COG, COF, Backlight, LCM and foreign advanced high-precision testing equipment.

  At the same time, the company has a group of experienced production engineering and technical personnel, who have been engaged in the LCD screen industry for many years.

  At present, the company has 120 employees, including more than 20 years of industry employees more than 40 people, who have rich experience in product process control and quality control.

  Dianguang is a high-tech enterprise specializing in designing and producing of TFT, liquid crystal display(LCD) module (LCM), touch screen (TP) and backlight (LED).

  LCD includes: VA, CTN, FSTN, STN, HTN, TN and so on; LCM includes: COB, TAB, COG, TP, LED backlight, etc.

  The company can design, research and produce a series of liquid crystal products, energy-saving photoelectric products, LED products and so on, according to the different needs of customers.

  For many years, "quality first, customer satisfaction" is our pursuit, our products have excellent performance and stable quality.

  In addition, they are deeply trusted and supported by customers.

  Dianguang's products are widely used in mobile phones, automobiles, industry, electricity, finance, consumer products and other fields.

  Such as POS machine, mobile phone, telephone, air conditioner, refrigerator, washing machine, electricity meter, water meter, gas meter, car audio, electronic dictionary, game machine, treadmill, etc.

  The company's products are in the forefront of the domestic industry in terms of technical level, product quality and product grade.

  The company carries out the management concept of "profession, innovation and progress".

  Through continuous perfection and improvement of management, scientific quality control is implemented to continuously improve the quality, we passed the ISO9001 quality system, IATF16949: 2016 quality management system certification.

  The company is committed to the producing,researching and developing of LCD&LCM, and has become a high-precision new technology enterprise in Hebei Province.

  "Reliable quality, professional service" is our consistent purpose.

  The company's products are exported to all over the world, including France, the United States, Japan, South Korea, India, Ukraine, the main export market proportion of more than 40%.

  The company is willing to sincerely cooperate with friends in the industry to seek common development and advance with the times.

  "Brilliant display, light up intelligent life".
