China Supplier Metric 90 Degrees Elbow Female Adjustable Bite Type Tube Fittings - China
price: 1.60 Dollar US$
Applications: Instrumentation, High pressure and temperature, Cryogenic service.
Specifications: Material: A105, Stainless Steel, Brass, Alloy 400(Monel), 2205 duplex stainless steel, Inconel, Hastelloy; Sizes: range from 1/16" to 2" and 2 mm to 50 mm; Maximum Operating Pressure: 15000psig(1034bar) @70℉(21℃); Operating Temperature Range: -325℉(-198℃) to 1200℉(648℃); Features: ♦ Fittings are easy to disconnect and retighten.
♦ Every fitting is stamped with size, material, and heat code.
♦ Radius junction design with elbows provides smooth flow path.
♦ Female nut threads are silver-plated to reduce the friction against the body threads.
♦ Hardened threads with smooth surface finish avoid galling and help to extend the fitting service life.
Company Contact:
- Posted By: Jiangsu Yicheng Fluid Equipemnt Co., Ltd.
- Phone: +86 15896371561
- Address: Lanling Road, Danyang , Jiangsu , China
- Email:
Published date: August 6, 2019
- Business Description: Jiangsu YiCheng Fluid Equipment Co.,Ltd was founded in 2008, our main products are tube fittings, pipe fittings, hose fittings, hydraulic fittings, flange and other products, widely used in high pressure hydraulic industry, cement industry, chemicals, fodd processing, nuclear, oil, gas, paper industry, railway and ship building.
