Pvc Cpvc Pvdf Pp Flow Meter - China

PVC Float Flowmeter model RPV164 is made by transparent AS body with PVC union connector and ABS coated steel floator, the function is to measure the flow rate of pipe system.

FLOW METER is easy to observe the flow inside the system, PVC flow meter measuring range from 5l/h to 200m3/h, connect size from 20mm to 160mm by socket, and DN15 to DN150 by flange.

Rota meter is used for water system and water treatment systems.

Basic specification

Size: DN15~DN150 (1/2 inch ~ 6 inch)

Connection: Flange, Socket

Body Material: AS, ABS, PVC

Floater material: ABS C/W steel

Measuring range: 5-50 l/h ~ 25-200 m3/h

Accuracy: 4%

Design pressure: 1.0Mpa (PN10 bar) Feature of flow meter

All the parts that touch medium are made by plastic and stainless steel.

Measureing range is widely.

Union design is convenient to install and replace.

Transparent body is convenient to observe the medium, and diagnosis problem.

Suitable for vertical installation only

Company Contact:

• Posted By: NINGBO RMI PLASTIC CO.,LTD

• Phone: +8618906745650

• Address: Shuiqin Industry Zone,Chaiqiao Street,Beilun Dist,Ningbo 315800,P.R.China, Ningbo , Zhejiang , China

• Email:

• Website: https://www.rmiplast.com

• Business Description: We are a professional manufacturer and exporter of plastic valves and piping materials, provide consult service and supply high quality piping materials for industrial application, water treatment system, irrigation systems, etc.

  RMI products cover full range of plastic valves, pipes, fittings and accessories by different materials of PVDF, PVC, PVC-C, PP, PP-H, PP-GF, FRP, EPDM, VITON, PTFE.
