Nickel Base Alloy Lined Pipe - China

Nickel matrix, can resistant corrosion in some medium, called the nickel-based corrosion resistant alloy.

The main alloying elements of nickel-based alloys are copper, chromium and molybdenum.

It has a good overall performance, resistance to various acid corrosion and stress corrosion.

The first application (1905 US production) is a nickel-copper (Ni-Cu) alloy, also known as Monel (Monel alloy Ni70Cu30).

There are also nickel-chromium (Ni-Cr) alloys (nickel-based heat-resistant alloy), nickel-molybdenum (Ni-Mo) alloys (mainly refers Hastelloy B series), nickel chromium-molybdenum (Ni-Cr-Mo) alloys (mainly refers Hastelloy C series) and the like.

At the same time, pure nickel is a typical representative of nickel based corrosion resistant alloys.

These nickel-based corrosion resistant alloy is mainly used in the manufacture of petroleum, chemical, power and other corrosion-resistant components of the environment.

Application:

 Subsea Pipeline

 Offshore Oil & Gas pipeline

 Onshore Oil & Gas pipeline

 Oil Refining & Petrochemical pipeline

 Power Plant pipeline

 Environmental Protection & Sewage Treatment Specification:

 Outer Diameter(mm): 20~1420

 Wall thickness(mm): Outer backing pipe 2.5~50;Liner steel pipe 0.25~7

 Composite Standard: API-5LD; DNV-OS-F101; DEP 31.40.20.32; CJ/T192;

 Packing: In bulk or according to customers’ requirements

The gripping force(σy) between the lining and the backing steel

Thickness of the lining /mm The gripping force/MPaG Remark ≥3.0 ≥150 2.0～3.0 ≥90 1.0～2.0 ≥60 ＜1.0 —— Untested
