Double gland zirconium plug valve

Zirconium plug valve

Plug valve

Manual Valve

zirconium valve, double gland plug valve

Technical Specification

Design Standard: API, ASME, EN, ISO, JIS, DIN, BS, GB

Connection type: Flange, SW, NPT, BW

Pressure range: 150LB~600LB, 1.0MPa~11.0MPa, JIS10K~40K

Size range: NPS1/2”-16”, DN15~DN400

Drive: Lever, Gear, Electric, Pneumatic actuator Design Feature:

Full bore or Reduce bore

Fixed structure

Double gland structure

Fire safe design, Anti-static device

Packing box design

Anti-erosion adjustable structure

The surface form a protective film after Hard face treatment on trim.

It not only improves anti-corrosion performance, but also can open and close easily because of improved surface hardness.

Main Part Material :

Zirconium 702, Zirconium 705

702C, 705C

R60702, R60705

Company Contact:

• Posted By: Weidouli Valves Co.,Ltd

• Phone: 8657786921659

• Address: No.20,Xingyu Road,Airport Industiral Zone,Wenzhou City,Zhejiang Province,P.R.China, Zhejiang , Wenzhou , China

• Email:

• Website: https://www.wsv-valve.com

• Business Description:

  Weidouli Special Valves(WSV), Chinas leading valve manufacturer, specialize

  in industrial valves production, research & development, sales and service.

  History

  Founded in 1989

  Factory

  1st Factory: 9500m2

  2nd Factory: 33600m2

  People

  160 staffs

  Quality

  (DNV) ISO9001, ISO 14001, OSHAS 18001, API 6D, API 607/6FA, CE , TS etc.

  approvals.

  Equipment

  Ov er 100 sets including CNC and multi-station, Vacuum welding equipment,

  Vacuum heat treatment furnace, Vacuum surface modification.

  Test

  equipments

  such as NITON XRF Alloy analyzer, Direct reading spectrometer, Metallurgical

  microscope, Ultrasonic thickness measurement, Burawoy hardness test,

  Nondestructive test etc.

  Specialty

  Entirely focused on industrial valves for severe services

  Product line

  WSV Valves are built in high corrosion resistant performance materials: duplex

  and super duplex, titanium alloy, nickel alloys (Hastelloy?, Incoloy?, Inconel?,

  Monel?, Alloy 20, etc.

  ), zirconium and corrosion resistant alloys across all major

  industrial applications.

  Our products includes ball, gate, check, globe, butterfly, plug, control etc.

  valves

  Application

  Valv es are delivered worldwide to the chemical engineering, mining project,

  metallurgy,

  pulp and paper making, power generation, natural gas and offshore and

  onshore other specific demand applications.

  Concept

  Coo perate sincerely, Create win-win
