Pipeline Transfer Circulation Booster Pump - China

pipeline pump is a centrifugal pump directly installed on the pipeline, with its inlet and outlet aligned in the same straight line.

It is used in series like a valve and primarily serves to boost and transport liquids.

1 - Pipeline pumps are single-suction single-stage or multi-stage centrifugal pumps with vertical or horizontal configurations.

They feature identical inlet and outlet ports aligned on the same central axis, allowing direct flange connection and installation in the pipeline without requiring additional suction piping.

2 - Relationship with Centrifugal Pumps: The pipeline pump is a special type of centrifugal pump, operating on the same principle (motor drives the impeller to rotate and generate centrifugal force for pressurization).

The difference lies in its more compact structure, coaxial inlet and outlet design that eliminates the need for a suction bend, and simpler pipeline layout.

Core working principle: The electric motor drives the pump shaft and impeller to rotate at high speed.

Liquid is drawn into the pump body and flows axially along the impeller, where centrifugal force pushes the liquid toward the outlet, increasing pressure to overcome pipeline resistance, enabling long-distance or elevated transport

Type and application

Classification by conveyed medium:

ISG-type water pump: Suitable for conveying domestic water and circulating water at normal temperatures, with a medium temperature range of -20°C to 80°C.

Commonly used in central air conditioning systems and factory circulating water systems.

Hot water pump (IRG type): Used for conveying boiler hot water and underfloor heating circulation water, with a medium temperature range of 80°C to 140°C.

The pump body is equipped with heat dissipation fins, and the mechanical seal is resistant to high temperatures.

Oil Pump (YG Type): Suitable for transporting gasoline, kerosene, and diesel with a medium temperature range of -20°C to 120°C.

Equipped with explosion-proof motors, it is used in the petroleum industry and oil depot pressurization.

Chemical Pump (IHG Type): 316L stainless steel pump body, suitable for conveying mild acid and alkali chemical media, corrosion-resistant.

Classified by installation form:

Vertical pipeline pump: The motor is vertically upward and occupies a small area.

It is installed on a horizontal pipeline and needs to be removed during maintenance.

Horizontal pipeline pump: The motor is arranged horizontally for easy maintenance, and the mechanical seal is easy to replace in the later stage.

It occupies a large area and is preferred for large power applications

Typical application scenarios: High rise building pressurized water supply, central air conditioning cooling/chilled water circulation, boiler hot water circulation, fire pressurization, industrial process liquid transportation, hotel and shopping mall tap water pressurization.
