Medium Sized Wastewater Distillation Evaporator 100l - China

Product information Equipment name: Wastewater distillation equipment

Processing objects: cutting fluid, cleaning fluid, sewage concentrate, etc.

Model: W100S Design capacity: 100L/H

Equipment size: 2900mmW×1600mmL×2000mmH (body size)

Total power: 30KW

Device schematic

pls contact us, we will send to you right away.

Configuration specifications: 1 - Distillation regenerator

Working principle: heating and boiling under vacuum to generate steam, distillation separation and concentration of waste liquid, and separation of water and oil.

Distilled water is reused, and the concentration rate can reach more than 70%

Distillation efficiency: 24L/hour

Distillation method: indirect heating of the compressor, distillation under reduced pressure, with automatic waste drainage system

Heating power: 30kw is compressor power 2 - Vacuum pump unit Working principle: vacuum extraction (negative pressure) for vacuum distillation tank

Specifications and models: 1 group: Baker vacuum pump U4.7, power 1.5kw, ultimate pressure-100kpa

Action mode: oil seal pump

Displacement: 10800L/min/set

Cooling: The heat exchanger is connected to the coolant, and a temperature detector is installed 3 - filtering system Working method: Circulate and filter the waste liquid to be treated in the early stage, prevent large particles of solid materials from entering the distillation tank, and classify and filter the waste liquid particulate impurities before distillation and separation

Circulation filter pump: "South" self-priming pump, power 0.75kw

Precision filter: "Biyun" bag filter

Filtration accuracy: 50μ before distillation regeneration (can be changed between 50-100 microns)

Before coarse filtration: metal filter

Inspection device: install pressure gauge and pressure switch, abnormal pressure alarm device
