Angle Rolling Stock Material Combustion Tester - China

The 45° angle rolling stock material combustion tester is suitable for the determination of the flame retardant properties of rolling stock flame retardant materials.

Special manual igniter is safe and reliable.

Product Name: 45 ° angle rolling stock material combustion tester Applicable standards.

For different standards, need to be equipped with different accessories:

TB/T 3138-2006 technical conditions of flame retardant materials for rolling stock

TB/T 2402-1993 flame retardant requirements for non-metallic materials for railway passenger cars

GA 303-2001 Flexible flame retardant polyurethane foam Scope of application:

Applicable to the combustion test of 45° angle of the flame retardant material of rolling stock material.

Technical conditions:

1 - Specimen 257mm×182mm

2, The specimen is placed at an angle of 45° at an angle of tilt

3, fuel container bottom center to the center of the sample vertical distance of 25.4mm

4, fuel container ¢ 17.5mm × 7.1mm, t0.8mm

5, Test conditions: temperature 15℃~30℃, humidity 60%RH~75%RH ps: (WLJCDM809)

web: tag:

45 degree flammability tester, flammability tester, flammability, 45° flammability tester, automatic flammability tester, textiles 45 degree flammability tester, 45 degree automatic flammability tester, flammability testing equipment, 45° flammability test machine, spi flammability tester, flammability testing, flammability test chamber, 45degree flammability tester, vertical flammability tester, 45 degree flammability test chamber, horizontal flammability tester
