Environment Friendly Prefab Container House White 5800mm 2250mm 2500mm - China

Environment Friendly Prefab Construction Housing 5800mm*2250mm*2500mm Product Introduction KAYI Prefab Construction Housing has the characteristics offlexible assembly, environment friendly, safe and comfort, now has benn widely used to Large - scale Events, Construction Site, Guard House, Workshop, Plant, Temporary Office, etc.

5800mm*2250mm*2500mm is one of the standard sizes of KAYI Prefab Construction Housing, easy to transport and assemble highly, which is your best choice.

Product Parameter - - - - Specification: Standard Container | Length(mm) | 5800 | Width(mm) | 2250 | Height(mm) | 2500 | Roof Type | Flat Roof with internal water draining design | Storey | 3 | Design Data (standard) | Design Serrvice Life | 25 Years | Floor Live Load | 2.0 KN/m2 | Roof Live Load | 0.5 KN/m2 | Weather Load | 0.6 KN/m2 | Seismic | 8 Degree | Structure | Corner Post | Galvanized Cold Roll Steel, Material: Q235B | Roof Main Beam | Galvanized Cold Roll Steel, Material: Q235B | Roof Sub-beam | Galvanized Cold Roll C Steel, Material: Q235B | Base Beam | Galvanized Cold Roll Steel, Material: Q235B | Base Sub-beam | Galvanized Cold Roll C Steel, Material: Q235B | Metal Surface Treatment | Using graphene powder electrostatic spray or paint spraying.

| Roof | Roof Panel | SGLC color steel sheet, Color: White-gray | Insulation | Glass wool, with single side aluminum foil, Class A fire rating ( Non-combustible) | Top Ceiling | SGLC color steel sheet, Color: White-gray | Floor | Floor Surface | PVC Flooring.

Color: Light Gray | Base | Cement Fiber Board, Density1.3g/cm2 | Insulation(Optional) | Glass wool, with single side aluminum foil, Class A fire rating ( Non-combustible) | Base External Plate ( Optional) | SGLC Sheet | Wall | Interface | S type interface (cold biidge effect) | Color Steel Sheet | Aluminum zinc coated steel color embossed plate | Bulk Density | Glass wool(Density: 64kg/m3)or Rock wool (Density: 85kg/m3) | Door | Specification (mm) | W*H=850*2030 | Material | Steel Door | Window | Specification (mm) | W*H=1150*1100 | Frame Material | UPVC, 60 series | Glass | 5mm double glaze | Electrical | Voltage | 220v-250v | Electrical Wire | Electrical Wiring: 6m2, AC and power socket wiring: 4m2, standard socket wiring: 2.5m2, Lighting Switch wiring: 1.5m2 | Breaker | High breaking miniature circuit breaker | Loght Tube | Double tube Lamp, 36W, 2 Units | Water | Socket | 4 five holes socket 10A, 1 three holes AC socket 16A, GB | Inlet Pipe | PPR | Outlet Pipe | UPVC | Standardized construction, equipment and fittings accord with GB | - - - - Product Features 1)Fast and Efficient All products and components adopt factory prefabrication, standardized production, convenient transporation and fast on - site assembly.

(3 workers, 1 crane, 10-20 units assembled per day) 2) Flexible Assembly Horizontal infinite connection, vertical free stack, vertical up to 3 layers, and can be set up stairs and pllatforms.

3) Environment Friendly Modules are esaily removable at the end of the project making the site in its initial conditions and appearance.

To ensure the concept of "zero waste" on site.

Product Application warehouse, storage, dormitory, kitchen, shower room, locker room, meeting room, classroom, shop, portable toilet, sentry box, mobile kiosk, motel, hotel, restaurant, and residential houses, temporary office, temporary hospital, dining-room, field and outdoor work station and so on.

Compare Container House And Common House * Container house can be use directly, no need installation, fast moving, can be reused so very economical and environment-friendly.

* Prefabricated container house is cheaper, needs to be installed locally but very fast, usually a 40HC container can hold 6-8 sets 6*2.5m prefab house.

Container House, Shipping Container Home
