Xlpe Nf C 33 209 Lv Abc Aerial Power Cable 600v Service Bundled Conductors - China
price: check with company for price
NF C 33 209 LV-ABC Aerial Bundled Cable 600V Service Bundled Conductors APPLICATION The power cables with cross-linked polyethylene (XLPE) insulation for overhead lines are designed for electrical installations with alternating power networks with nominal voltage Uo/U 0.6/1 kV or in direct power networks with maximum voltage according to land 0.9 V.
The cables with supporting (bearing) zero conductors are used for building networks in city and urban areas and the self-supporting type cables are for building distribution networks in these areas.
Cables for overhead installations may be used in different types of installations: on free hanging facades; between posts; on fixed facades; trees and poles.
Interception of forest areas without the need of clearance and maintenance of openings is allowed.
-Cables with supporting zero conductor, the whole bundle is suspended and carried by the supporting conductor, which is made of aluminum compound.
- Self-supporting construction, suspension and carrying of the whole bundle is done by the phase insulated conductors.
Bundles can include one or two additional conductors for public lighting and control pair.
SPECIFICATIONS Operating temperature: 80 Short-circuit temperature: 130 Nominal voltage : Uo/U 0.6/1 kV Highest system voltage AC, not more than: 1.2 kV Test voltage C -5 min 4 kV DC - 15 min 10 kV Bending radius, min.
18xD cable Temperature of laying no less than - 10 Conductor resistance at 20: 16 - 1.91 / 50 - 0.641/ 25 - 1.20 / 70-0.443 / 35 - 0.868/ 95 - 0.320/ 54.6Alm - 0.63/;70Alm- 0.5/ 95Alm - 0.343/ Supported neutral breaking strength min.
for 54.6 - 16.6N for 70 - 20.50kN for 95 - 27.50N DIMENSIONS - - - - Number of conductors and nominal cross section | Thickness of insulation M/N/R | Diamete r of bundle approx.
| Allowed current in power supply networks | Allowed current in distribution networks | l/R | Mass of l cores approx.
| Cable weight approx.
| n mm2 | mm | mm | | | kg/km | kg/km | | | | | walls/air/facades | | | | | | | | | | 2x16 | 1.2 | 15 | - | 72 / 93 / 83 | 91 | 125 | 2x25 | 1.4 | 18 | - | 95 / 122 / 111 | 142 | 165 | 4x16 | 1.2 | 18 | - | 63 / 83 / 75 | 183 | 260 | 4x25 | 1.4 | 22 | - | 83 / 111 / 99 | 285 | 395 | | | | | | | | 3x25+54.6Alm | 1.4/1.6 | 30 | 112 | - | 369 | 505 | 3x25+54.6Alm+Kx16 | 1.4/1.6/1.2 | 30 | 112 / 83 | - | 460 | 635 | 3x35+54.6Alm | 1.6/1.6 | 33 | 138 | - | 455 | 615 | 3x35+54.6Alm+Kx16 | 1.6/1.6/1.4 | 33 | 138 / 83 | - | 546 | 745 | 3x50+54.6Alm | 1.6/1.6 | 36 | 168 | - | 583 | 725 | 3x50+54.6Alm+Kx16 | 1.6/1.6/1.2 | 36 | 168 / 93 | - | 674 | 860 | 3x50+54.6Alm+Kx25 | 1.6/1.6/1.4 | 36 | 168 / 111 | - | 725 | 925 | 3x70+54.6Alm | 1.8/1.6 | 37 | 213 | - | 754 | 950 | 3x70+54.6Alm+Kx16 | 1.8/1.6/1.2 | 40 | 213 / 83 | - | 845 | 1080 | 3x70+54.6Alm+Kx25 | 1.8/1.6/1.4 | 40 | 213 / 111 | - | 896 | 1150 | | | | | | | | 3x70+70Alm | 1.8/1.5 | 41 | 213 | - | 798 | 984 | 3x70+70Alm+Kx16 | 1.8/1.5/1.2 | 41 | 213 / 83 | - | 889 | 1115 | 3x70+70Alm+Kx25 | 1.8/1.5/1.4 | 41 | 213 / 111 | - | 940 | 1185 | | | | | | | | 3x95+54.6Alm | 1.8/1.6/ | 44 | 258 | - | 967 | 1195 | 3x95+54.6Alm+Kx16 | 1.8/1.6/1.2 | 44 | 258 / 83 | - | 1059 | 1325 | 3x95+54.6Alm+Kx25 | 1.8/1.6/1.4 | 44 | 258 / 111 | - | 1110 | 1355 | | | | | | | | 3x95+70Alm | 1.8/1.5 | 44 | 258 | - | 1011 | 1355 | 3x95+70Alm+Kx16 | 1.8/1.5/1.2 | 44 | 258 / 83 | - | 1102 | 1615 | 3x95+70Alm+Kx25 | 1.8/1.5/1.4 | 44 | 258 / 111 | - | 1154 | 1485 | 3x120+70Alm | 1.8/1.5 | 46 | 300 | - | 1225 | 1445 | 3x120+70Alm+Kx16 | 1.8/1.5/1.2 | 46 | 300 / 83 | - | 4828 | 1575 | 3x120+70Alm+Kx25 | 1.8/1.5/1.4 | 46 | 300 /111 | - | 1368 | 1610 | | | | | | | | 3x120+95Alm | 1.8/1.6 | 47 | 300 | - | 1296 | 1535 | 3x120+95Alm+Kx16 | 1.8/1.6/1.2 | 47 | 300 / 83 | - | 1387 | 1660 | 3x120+95Alm+Kx25 | 1.8/1.6/1.4 | 47 | 300 / 111 | - | 1439 | 1735 | | | | | | | | 3x150+70Alm | 1.7/1.5/ | 48 | 344 | - | 1482 | 1670 | 3x150+70Alm+Kx16 | 1.7/1.5/1.2 | 48 | 344 / 83 | - | 1573 | 1795 | 3x150+70Alm+Kx25 | 1.7/1.5/1.4 | 48 | 344 / 111 | - | 1624 | 1870 | - - - -
Company Contact:
- Phone: 86-27-82757025
- Address: Room B813,No.61, Yejin Avenue, Qingshan District,Wuhan City, Hubei Province, China, Wuhan , Hubei , China
- Email:
Published date: March 20, 2018
- Business Description: UNI-CABLES, Brand owned by a group company of WUMEE, which now has four factories in China.
Wuhan Unique Electric Wire and Cable Co., Ltd, Guangdong Unique Cable Co., Ltd, Guangxi Unique Aluminum Co., Ltd, Wuhan Unique No.
2 Factory.
