  • High Absorption Solar Hot Water Collector - China

    price: check with company for price

    High Absorption Blue Titanium Anodised Aluminium Alloy Flat Plate Solar Collector Specifications Flat Plate Solar Collectors 15 years lifespan, 3 years warranty easily installing, minimal maintenance 3 kinds of coating EU High Quality Pressurized Flat Plate Solar Collectors SOLAR KEYMARK certified Technical Data Absorber coating: blue titanium sputtering Optical performance: Absorption: ~95% / Thermal Emission: ~5% Frame Casing: width: 85mm; corrosion-resistant and elegant-design Cover glass: tempered patterned glass, 4.0mm, high transmittance>89% Insulation: 25mm soft fiberglass layer + 25mm high- density fiberglass board Back sheet: embossed aluminum plate 0.5mm Sealing profile: EPDM Connection: 22 Gross /Aperture area: 2 sqm/1.85sqm Gross size: 2000mm*1000mm (L*W) Header tube: full copper TP2, 1060mm*22mm*0.6mm (L*OD*Wall thickness) Riser tube: full copper TP2, 1886mm*10mm/*0.45mm(L*OD* Wall thickness) Fin: copper 0.15mm Operation pressure: 600Kpa ( 6bar) Features for flat plate solar collectors Reliable, efficient, environment-friendly and energy-free from the solar energy, save your money.

    Unique panel structure, faster heat transfer speed, not easy to accumulate dirt.

    Outstanding antifreeze performance, working normally in winter.

    Aluminum alloy frame and also tempered glass, giving you a luxurious taste.

    easy installation, beautiful appearance, well integrated with building; minimal maintenance after that.

    can be connected into series to increase hot water capacity.

    long lifespan, much value than the money you invest first.

    pressure standing.

    no blasting problem like vacuum tube.

    - - - - Model No.

    | PT-FPC01 | PT-FPC02 | PT-FPC01 | PT-FPC01 | Thermal Insulation | Insulation Material | 16KRock wool(back)EPS plate Polyurethane(side) | 16KRock wool(back)EPS plate Polyurethane(side) | 60k.

    50mm rock wool Polyurethane(side) | 60k.

    50m rock wool Polyurethane(side) | Insulation Thickness | 40mm(back)/25mm(side) | 50mm(back)/30mm(side) | | | Conductivity(W/mK) | 0.032 under 75c | 0.042 under 75c | 0.032 under 75c | 0.032 under 75c | Casing | Frame | Aluminum alloy frame(Rectangular) | Aluminum alloy frame(Rectangular) | Aluminum alloy frame(Rectangular) | Aluminum alloy frame(Rectangular) | Frame Color | Bronze color | Bronze color | Bronze color | Bronze color | Back Plate | 0.3mm Galvanized Steel | 0.3mm Galvanized Steel | 0.5mm Galvanized Steel | 0.5mm Galvanized Steel | Max Operation Temperature | 180c | 200c | 180c | 200c | Maximum Pressure(Mpa) | 0.6 | 1.4 | 0.6 | 1.4 | Sealing Gasket | EPDM | EPDM | EPDM | EPDM | Limitation of Operation | Max.

    Working Temperature | 120c | 120c | 120c | 120c | Max.

    Working Pressure | 0.5Mpa | 1.2Mpa | 0.5Mpa | 1.2Mpa | Recommended Circulation Flow | Water | Propylene glycol&water mixture | Water | Propylene glycol&water mixture | Resistance to Freezing | 0c | -40c | 0c | -40c | - - - - Warranty 10 years international responsibility for Flat Plate Panel Solar Collector due to original quality problems.

    FAQ Model selection: We suggest 40 - 50 liter hot water for one person in a single day, for colder area larger aperture area is suggested for same tank liter.

    Optional device: Choose by yourself or rely on our 10 years export experience for consultation.

    Connection: Size and location for tank connection can be customized or suggested by our experienced stuff.

    OEM: Your LOGO information can be on the flat plate solar water heater and carton boxes.

    ODM: Design can be made according to your actual requirements.


    Company Contact:


    • Phone: 86-135-11388384

    • Address: YUANHUA, HAINING, ZHEJIANG, CHINA, HAINING , ZHEJIANG , China

    • Email: Email


    Published date: April 19, 2018

    • Business Description: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. is a manufacturer of Solar Water Heater since 1996.

      As an experienced company, we can provide the perfect solution for Solar Thermal System.

      Our products include solar water heater, solar collector and accessories.
