  • Hydraulic Control Glazed Tile Roll Forming Machine For Construction Metal Making - China

    price: check with company for price

    Hydraulic Control Glazed Tile Roll Forming Machine For Construction Metal Making 1 - Description: Thismodelofmachineiswidel yusedinAfricaandRussia.

    Th efeedingwidthis1200mm, andcoverwidth is1100, itisperfectlyoverlapped.

    S avematerialandoutlookisbe autiful.

    2 - Competitive Advantage: 1 - savespace 2 - easyinstallation 3 - perfectservice 4 - excellentquality 5 - Operateeasily 3 - Flowchart 4 - Specification - - - -

    NO.

    | ITEM | PARAMETER | NOTE | 1 | Suitable | Type | Pre-painted sheet, | | | | material | Galvanized sheet | | | | Galvanized Aluminum | | Width(mm) | 1250mm | | | Thickness(mm) | 0.3-0.8mm | | | Yield stress(mm) | Q235 | | 2 | Product | Detail as the attached file | | specifications | Length | Any length | | 3 | Power | Type | 380v/3ph/50hz | Motor brand shanghai | | Main Motor power | 7.5kw | | requirement | Lichao | 5 | Manual Decoiler | Type | Manual | | | Max capacity | 5t | | | Suitable coil OD(MM) | 1000 | | (Optional) | Suitable coil | 508 | | | | | ID(MM) | 6 | Forming stand | 14 | Depend on actual design | 7 | Thickness of structure | 16mm | | 8 | Forming shaft diameter(mm) | 70 solid | | 9 | Type of cutting | Roll formed and | | | length-set cutting | 10 | Control system | Panasonic PLC and inverter | | 11 | Install dimension(depend on the final design) | 7.3m1.5m1.2m | Without panel length | 12 | Total weight (Approx) | 3.5T | Depend on final design | - - - - 5 - Applications: - - - - | Our machine | Other company 's machine | Influence of the machine | Machine's base | High strength H350 / H400 steel.

    machine through milling macine after welding | H270 steel mark, after welding use manual polish | keep base in the samehorizontal line, ensureproduct standard | Roller material | High grade No.

    45 forged steel, with digital-controlled procession, Plated with 5 um chrome coated | Normal No.

    20 steel with Simple polished and have no coating | Roller will have longeruse life and ensure theproducts have same size, no nick on the surface.

    | Side wall | Use high strength16mm thickness steel panel mark | Use 12 mm thickness steel panel mark | Ensure machine harder todeform, keep the productaccurate and stable | Active shaft material | High grade solid No.

    45 carbon steel, Shaft diameter is 70mm.

    surface CNC polish treatmen | Normal No.

    45 steel with no surface treatment | Improve the integratedmechanic feature of theshaft.

    and ensure theshaft stability keep product standard | Electrical elements | PLC control panel, transducer imported from Panasonic of Japan.

    Other elements from famous suppliers in China | All the elements are made in china | Machine become moreaccurate and more stable | Cutter blade | Cr12 mould steel with quenched treatment | Normal high strength steel without quenched treatment | Stable the integrated mechanic feature of the cutter blade, harder to deform, longer blade's life, ensure product standard | - - - - Machine picture


    Company Contact:


    • Phone: 86-317-33711731

    • Address: Shengli Road Cangzhou Hebei province China, Cangzhou , Hebei , China

    • Email: Email


    Published date: April 10, 2018

    • Business Description: Master international trade Co., ltd is a professional manufacturer and exporter which has its own factory and also cooperate with several production factories and associated enterprises, concerning with the design, development and production of cold roll forming machines, material of building.
