Stainless Steel Galvanized Hexagonal Wire Mesh Gabion Boxes 0 5mm Thick Pvc Coated - China

Stainless Steel Galvanized Hexagonal Wire Mesh Gabion Boxes, 0.5mm Thick PVC Coated Steel wire used in the manufacture ishot-dip galvanizingorgalfan(zinc 95%, aluminum 5%).

If it is required, 0.5 mm thick PVCis then coated on the galvanized/galfan wire to provide added protection for use in aggressive environments with acidic soils and water, in salt or fresh water or wherever the risk of corrosion is present.

In order to reinforce the structure, the edge wire has a greater diameter than the mesh wire.

The gabion box is divided into units by means of diaphragms positioned at approximately 1m centres.

pvc gabion box which is the gabion woven by the hexagonal mesh, the diameter thickness depends on the mesh size, the diamter is between 2.0mm to 4.0mm if the material is zinc coated, while the diamter will be 3.0mm to 4.5mm if the material is PVC-coated wire, the selvage wire diamter usually is one gauge thicker than the body wire diamter.

Usage:

1 - Controlling and leading the river and flood 2 - Flood discharge and lead flow 3 - rock fall defending 4 - preventing the water and soil lost 5 - protecting the bridge 6 - reinforce fabric 7 - seashore recovery project 8 - seaport project 9 - block wall 10 - defending the road.

PVCgabionboxspecification : - - - - mesh(mm) | wire(mm) | wire(PVC)/inner/outside(m m) | biggestwidth(mm) | 60X80 | 2.0-2.8 | 2.0/3.0-2.5/3.5 | 4300 | 80X100 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | 4300 | 80X120 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | 4300 | 100X120 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | 4300 | 100X150 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | 4300 | 120X150 | 2.0-4.0 | 2.0/3.0-3.0/4.0 | 4300 | - - - - Engineering Projects:
