Glsun 2x2f Fiber Optic Switch - China

2x2 Optical Fiber Switch - Introduction

SUN-FSW-2x2F mechanical optical fiber switch, which is famous for its high performance, low insertion loss and compact dimension: (L)27.0x(W)12.6x(H)8.2 ±0.2 - It is an ideal component for OADM, OXC, system monitoring and protection.

GLSUN fiber optic switches can be widely used in optical network protection, transmitter and receiver protection, network test system and instrumentations.

Features

Low Insertion Loss

Wide Wavelength Range

Low Crosstalk

High Stability, High Reliability

Epoxy-free on Optical Path

Latching and Non-latching Application

R&D in Laboratory

System Monitoring

OADM

MAN (Metropolitan Area Network) Specification

2x2 Optical Fiber Switch - Specification

Parameters

Unit

SUN-FSW-2x2F

Wavelength Range

nm

850±40 / 1300±40

1260 ~ 1650

Test Wavelength

nm

850 / 1300

1310 / 1550

Insertion Loss 1, 2

dB

Typ: 0.8 Max: 1.2

Typ: 0.8 Max: 1.0

Return Loss 1, 2

dB

MM ≥ 30 SM ≥ 50

Crosstalk 1

dB

MM ≥ 35 SM ≥ 55

PDL

dB

≤0.05

WDL

dB

≤0.25

Repeatability

dB

≤±0.02

Operating Voltage

V

3 or 5

Durability

Cycles

≥ 10 Million

Switching Time

ms

≤8

Optical Power

mW

≤500

Operating Temperature

℃

-20 ~ +70

Storage Temperature

℃

-40 ~ +85

Relative Humidity

%

5 ~ 95

Weight

g

14

Dimension

mm

(L)27.0×(W)12.6×(H)8 .

2 ±0.2

Note:

1 Within operating temperature and SOP.

2 Excluding Connectors.
