High Isotropy Hot Work Tool Steel Skd61 4cr5mosiv1 Flat Bar 51 55hrc Hardness - China

1.2344 / H13 / SKD61 / 4Cr5MoSiV1 Flat Bar and Round Bar of Hot Work Tool Steel 1 - Features a, Electro slag remelting, annealing with diffusion process and ultrafining heat-treatment has good microstructuahomogeneity and finer dispersed carbides.

b, High isotropy, aspect rations0.8 c, Good tempering performance, high toughness, high temperature strength, good thermal stability and thermal fatigue resistance.

d, Annealing hardness230HB, quenching hardness 51-55HRC, tempering hardness 46-50HRC 2 - Equivalent Grades - - - - GB | DIN | AISI | JIS | ASSAB | 4Cr5MoSiV1 | 1.2344 | H13 | SKD61 | 8407 | - - - - 3 - Available Size (mm) - - - - Flat Bar Size(mm) | Round bar Size(mm) | Thickness | Width | Length | Diameter | Length | 16-260 | 205-610 | 3000-6000 | 16-200 | 300-6000 | - - - - 4 - Chemical Composition (%) - - - - Grade | C | Si | Mn | P | S | Cr | Mo | V | H13 | 0.32-0.45 | 0.80-1.20 | 0.20-0.50 | 0.030 | 0.030 | 4.75-5.50 | 1.10-1.75 | 0.80-1.20 | SKD61 | 0.32-0.42 | 0.80-1.20 | 0.20-0.50 | 0.030 | 0.030 | 4.75-5.50 | 1.10-1.75 | 0.80-1.20 | 1.2344 | 0.38-0.42 | 0.80-1.20 | 0.30-0.50 | 0.015 | 0.020 | 4.80-5.50 | 1.20-1.50 | 0.90-1.10 | 4Cr5MoSiV1 | 0.32-0.45 | 0.80-1.20 | 0.20-0.50 | 0.030 | 0.030 | 4.75-5.50 | 1.10-1.75 | 0.80-1.20 | - - - - 5 - Recommend Heat Treatment - - - - quenching | tempering | Heating temperature/ | Cooling way | Hardness (HRC) | Tempering temperature /C | Tempering number | Hardness (HRC) | First preheating | Second preheating | Last heating | 500-550 | 750-800 | 1020-1050 | Oil Cooling or Air Cooling | 56-58 | 560-580 | 3 | 40-45 | - - - - 6 - Applications 1.2344 H13 SKD61 4Cr5MoSiV1 Flat Bar Round Bar[ Tooling Steel] belong to multi function Machinery chromium hot work tool steels which are much widely using on hot and cold work tooling applications.

1.2344 H13 SKD61 4Cr5MoSiV1 [tool steel] is classified as range H steels by the AISI classification system range.

This range of steels start from H1 to H19 - In steel Flat Bar Round Bar 1.2344 H13 SKD61 4Cr5MoSiV1, the molybdenum & vanadium acting as strengthening.

The chromium content assists die steel 1.2344 H13 SKD61 4Cr5MoSiV1 to resist softening when using at high temperatures.

1.2344 H13 SKD61 4Cr5MoSiV1 die steels offers outstanding combination of shock and abrasion resistance, and possesses good red hardness.

It's capable of withstanding rapid cooling and resists premature heat checking.

Tool Steel H13 has good machinability, good weldability, good ductility, and can be formed by multi function Machinery conventional means.

Due to Flat Bar Round Bar 1.2344 H13 SKD61 4Cr5MoSiV1 tool steel excellent combination of very high toughness and fatigue resistance, AISI H13 hot work tooling steel is using much more than other tooling steel in tooling multi functional applications.

Our service Our company have introduced large-sized vertical saw machines, horizontal saw machines, milling machines, grinding machines and other advance equipments, we can export our products by wholesales and retail sales, whole plate or strip is available.

All our products can meet the standards of DIN, AISI, JIS and GB, all the material should be inspected the ultrasonic, hardness and others strict inspection process before the shipment.

a, Sizes, materials and others are all at your requirements and can be changed; b, Price varies on materials, dimensions, finish craft and different payments; c, We are direct manufacture in machinery manufacturing work with experience of several decades; d, Detail production design will be made according to information you offered; e, We have adequate inventory, so that we can quick delivery; f, The most important is that we have advanced equipment.
