Fog North Seeking Gyro - China

price: 100.00 Dollar US$

FOG inclinometer use Fiber Optic Gyro and accelerator as main sensors. It is single and multi-point inclinometer, Main features are stronger shock resistance and more reliability. FOG can be used for well trajectory repeated survey, sidetracking well directional.
Technical performance :
1. Parameter and accuracy :
Azimuth: 0°~360 °± 1.5 °
Well Inclination:0°~70 ° ± 0.15 °
Gravity tool face:0°~360°± 1.5 °
North tool face:0°~360 °± 3 °

2 .Environmental conditions :
Temperature:-20 ℃~80 ℃
(150 ℃ With heat shield )
Pressure resistance:80Mpa 。
Impact resistance:700g, 0.5ms, ½sine

3.Dimensions :
Down hole pressure shield diameter:45mm (48mm With heat shield )
Standard R guide shoe or E guide shoe


Company Contact:


  • Phone: 86-29-87545860-609

  • Address: Room 15A, RuiXin Building, High-tech Road 25th, Xi'an, China

  • Email: Email


Published date: November 14, 2016 -

  • Business Description: Ericco International limited was established in 2006 which is a professional provider of sensors for oil and gas exploitation, positioning and navigation in both civil and military application. We are specially engaged in providing different sensors such as Accelerometer, Dynamically Tuned Gyro, Fiber Optic Gyro, North seeking system etc. for downhole survey and borehole logging. Meanwhile our high precision sensors also bring customer excellent experience in developing navigation system.
