General Purpose Relays 24vdc G5nb 1a E Dc24 - India

price: 1.00 Dollar US$

General Purpose Relays SPST-NO Flux-Tight 24VDC High-Capacity :- G5NB-1A-E-DC24

FEATURES:-

• Max size 20.5L x 7.2 W x 15.3 W mm.
• Standard models switch up to 3 A High-capacity models switch up to 5 A (AC loads only).
• Low power consumption (200 mW).
• Semi-sealed and sealed types available.
• UL recognized / CSA certified. VDE Approved.
• RoHS Compliant.

APPLICATION:-

Water Heaters, Refrigerators, Air Conditioners, And Small Electric Appliances

DESCRIPTION:-

Product Category: General Purpose Relays
Manufacturer: Omron
RoHS: RoHS Compliant Details
Coil Voltage: 24 VDC
Contact Form: SPST (1 Form A)
Mounting Style: Through Hole
Coil Type: Non-Latching
Coil Resistance: 2.88 kOhms
Coil Current: 8.3 mA
Brand: Omron Electronics
Height: 15.3 mm
Length: 20.5 mm
Packaging: Bulk
Power Consumption: 200 mW
Series: G5NB
Factory Pack Quantity: 500
Width: 7.2 mm
Part # Aliases: 24DC 666415 G5NB-1A-E G5NB-1A-E-DC24-BY-OMZ G5NB-1A-EDC24 G5NB1AEDC24BYOMZNA
