Copper Pipe High Frequency Induction Hardening Machine - China

price: 56000.00 Dollar US$

Parameters of Copper Pipe High Frequency Induction Hardening Machine:
Max power: 160kw
Oscillating frequency: 10-35KHZ
Maximum input current: 240A
Input voltage: 380V, 3 phases, 50-60Hz
Generator Size(mm):720*520*1050
Transformer Size(mm):780*480*550
Generator Weight:95kg
Transformer Weight:130kg
Cooling water pressure: 0.3mpa

Advantages of Copper Pipe High Frequency Induction Hardening Machine:
1.Special cycle cooling system, make sure the machine work 24 hours continuously.
2.The induction heating equipment mains circuit adopts Siemens IGBT and any other new type induction heating machine.
3.Easy operation, can be equipment with PLC controller.
4.Energy saving, Environmental protection, Low pollution level.
5.It has the function of manual, semi-automatic, full-automatic and divide period to control, it is more convenient use.
6.perfect system of protecting itself when over current, over voltage, lack of water, phase fail, over hot, etc.

Main applications of Copper Pipe High Frequency Induction Hardening Machine:
1.Hardening of various hardware and tools, such as plier, wrench, hammer, ax, screwing tools and shear (orchard shear).
2.Hardening of various hardware metal parts and machined parts, such as shaft, gear (chain wheel), cam, chuck and clamp etc.
3.Hardening pin, piston ring, spring pin, valve, shifting fork.
4.Hardware molds hardening, such as small-size mold, mold accessory and inner hole of mold.
5.Hardening parts of automobile, motorbike, mold, agricultural machinery.

If you are interested in our equipment, please consult our website or contact us through dialling our hotline!

Company Contact:

  • Phone: 86-15538376386

  • Address: Jingnansi Rd., Economic-Technological Development Zone, Zhengzhou City,Henan,China, Zhengzhou, Zhengzhou, China

  • Email: Email

Published date: November 28, 2016 -

  • Business Description: High frequency, medium frequency, super-audio frequency, ultra-high frequency induction heating equipment.
