5vdc Power Relay G5rl 1a E Hr Dc5 - India

price: check with company for price

16A 5VDC SPST-NO PCB Power Relay - G5RL-1A-E-HR DC5

FEATURES:-

• Low profile: 15.7 mm in height.
• Creepage distance 8mm between coil and contacts
• 10 kV Impulse withstand voltage
• Models with AC coil available.
• High-Inrush model available (Inrush peak currents up to 100 A)
• Low Noise models available (Approx. 10 to 20 dB less sound
pressure than standard G5RL-Series Relays)
• TV8 Rating models available (TV8 for UL standard)

APPLICATION:-
• Housing equipments
• Audio-visual products
• Office automation machines
• Air-conditioners
• Lighting

DESCRIPTION:-
Manufacturer: Omron
Product Category: General Purpose Relays
RoHS: RoHS Compliant
Brand: Omron Electronics
Product: Power Relays
Type: Polarized
Coil Voltage: 5 VDC
Contact Form: SPST (1 Form A)
Contact Current Rating: 16 A
Contact Termination: Solder Pin
Mounting Style: Through Hole
Switching Voltage: 250 VAC, 24 VDC
Coil Termination: Solder Pin
Coil Type: Non-Latching
Coil Resistance: 47.2 Ohms
Coil Current: 106 mA
Contact Material: Silver Alloy
Height: 15.7 mm
Length: 29 mm
Packaging: Bulk
Power Consumption: 400 mW
Series: G5RL
Factory Pack Quantity: 100
Width: 12.7 mm


POPULAR PRODUCTS:-Omron G2RL Relay, Omron G5V relay, Omron G5LE Relay, Omron G5V-2 Relays, Power latch relay, Power magnetic relay, power monitering relay, power off relay, power on relay, Power pcb relay supplier, pcb cube relay, general purpose relay, Electronic pcb relay, electrical relays, power relay 16a, power relay 10a, 5vdc power relay, 5 pin power relay, 8 pin power relay etc.


Company Contact:


  • Phone: 9810618342

  • Address: SCF#- 17, 2nd Floor, Opp. Satyam Guest House, Sec. 16, Faridabad -121002, Haryana, faridabad, haryana, India

  • Email: Email
