Stainless Steel Lined Pipe - China

Stainless steel lined pipe adopt to compound stainless steel tube on the inner wall of outer backing pipe.

This lined pipe is greatly improved in watersupply, sewage treatment, oil & nature gas transportation in the process of corrosion resistance, smooth surface, Small fluid resistance; and retain the high mechanical strength of steel pipe, pipeline was connected by welding, groove, thread connection, good sealing, it overcomes the easy corrosion to steel pipe, the defects of easy leakage and aging of plastic pipes with hot melt connection, It is an ideal product for the upgrading of gas, water and oil pipeline.

Application:

 Oil &Gas transportation pipeline

 Power Plant pipeline

 Paper and Pulp industry

 Pharmacy & Medical  Water supply pipeline

 Food & Beverage pipeline Specification:

 Material of liner pipe: 304, 316L, 2205, Duplex Stainless Steel, Austenitic Stainless Steel

 Outer Diameter(mm): 20~1420

 Wall thickness(mm): Outer backing pipe 2.5~50;Liner steel pipe 0.2~6

 Composite Standard: API-5LD;DNV-OS-F 101;DEP 31.40.20.32; CJ/T192;

 Packing: In bulk or according to customers’ requirements.

 MOQ(Meters): 100

The gripping force(σy) between the lining and the backing steel

Thickness of the lining /mm The gripping force /MPaG Remark ≥3.0 ≥150 2.0～3.0 ≥90 1.0～2.0 ≥60 ＜1.0 —— Untested

Company Contact:

• Posted By: Bobpipe Engineering (Shanghai) Co.,Ltd

• Phone: +86-18110385044

• Address: Area C,High-Tech Building,No 900 Yishan Road,Xuhui District, Shanghai , Shanghai , China

• Email:

• Website: http://www.bobpipe.com

• Business Description: We are the leading manufacturer of Corrosion Resistant Alloy Lined/Clad Pipes (inner CRA layer normally includes stainless steel, Duplex, Nickel alloy, Titanium, Hastelloy etc), Fittings etc.

  Meanwhile, supply pipes/tubes, steel sheet, steel coil, flanges, piping system, water supply solutions etc services.

  Our products has been widely used in Oil & Gas transportation, Petrochemicals, Desalination & Salt Chemical, Medical, Nuclear & Power, Water supply and treatment, Food & Beverage etc.
